Introduction

Hamac soundproof generator is well improved. Its advantages as below:

1. All series soundproof genset could be lifted by the hook on the top;
2. The structure is more compact, there is big silencer inside to make the noise lower;
3. A special air flow design to prevent the dust and impurity to be sucked into the bin; the air inlet and outlet area is enlarged;

Specification

Genset model	Diesel engine model	Standby power		Prime power		Fuel consumption	Net weight	Dimension			Download
		KW	KVA	KW	KVA	L/H	KGS	L*W*H (mm)
HAC36GS	4BT3.9-G2	36	45	30	38	8	1300	2140	950	1370
HAC50GS	4BT3.9-G2	50	63	45	56	12	1420	2140	950	1370
HAC75GS	6BT5.9-G2	75	94	68	85	17	1650	2690	950	1370
HAC100GS	6BT5.9-G2	100	125	90	113	23	1700	2690	950	1370
HAC120GS	6BTAA5.9-G2	120	150	100	125	26	1800	3000	1140	1500
HAC160GS	6CTAA8.3-G2	160	200	140	175	36	1900	3980	1500	1750
HAC220GS	6LTAA8.9-G2	220	275	200	250	52	2800	3980	1500	1750
HAC280GS	NTA855-G2	280	350	250	313	61	3150	3900	1500	1750
HAC315GS	NTA855-G4	315	394	280	350	68	4620	3900	1500	1750
HAC400GS	KTA19-G3	400	500	350	437.5	98	4780	4150	1700	2000
HAC440GS	KTA19-G4	440	550	400	500	98	4980	4250	1700	2000
HAC800GS	KTA38-G2A	800	1000	720	900	178	9800	5820	2800	2750
HAC1100GS	KTA50-G3	1100	1375	1000	1250	245	20400	12300	2350	4210



Note: All technical parameter are subject to change without notice.
